TELESCOPIC BOOM LIFT -BT24RT
Model No : BT24RT
A Telescopic Boom Lift is designed to provide exceptional horizontal outreach and maximum working height for applications requiring direct access to elevated work areas. With its straight boom design, it enables operators to reach distant work locations quickly and efficiently, making it the preferred choice for large-scale industrial, infrastructure, and construction projects.
Whether you're working on steel structures, warehouses, airports, power plants, bridges, or high-rise buildings, telescopic boom lifts offer superior reach, stability, and productivity while ensuring operator safety.
| Model No | BT24RT |
|---|---|
| Working Height | 25 |
| Power Type | Diesel |
| Platform Height (m) | 22.8 |
| Platform Size (LxW) | 2.44x0.9 |
| Overall height (Rails up) (m) | 14300 |
| Ground clearance (m) | 0.41 |
| SWL (Kg) | 300 |
| Wheelbase (m) | 2.8 |
| Power source (k.w.) | Diesel |
| Gradeability | 45 |
·
2.31m (7ft 7in) Jib Boom
·
Front
Oscillating Axle
·
Four-Wheel Steering
·
Four-Wheel Drive
·
Self-Leveling Platform
·
180° Left
And Right Swing Platform
·
Proportional Joystick Controls
·
Thumb
Rocker Steer
·
Drive
Enable
·
Ac Power
Cord To Platform
·
Tilt
Alarm
·
Descent
Alarm
·
Flash
·
Horn
·
Hour
Meter
·
Integral
Integrated Special Drive Axle For Construction Machinery
·
360°
Continuous Turntable Rotation
·
Positive
Traction Four Wheel Drive
·
Platform
Load Sense System
·
Fault
Diagnosis System
·
Operator
Anti-crushing Protection System
·
Harsh
Environment Kits (includes Cylinder Sleeves, Boom Dust Kits, Ground And
Platform Control Box Covers)
·
12V DC
Auxiliary Power
·
Deutz
TD2.9 L4 55.4kW /2600rpm Diesel Engine *
·
Hydraulic
Oil Radiator
·
Anti-restart Engine Protection
·
Anti-reverse Engine Device
| No. | Name |
|---|---|
| 1 | Outdoor |
| 2 | Maintenance |
